Automatic L-Sealer+BD Shrink Tunnel +Kissing Device

APPLICATIONS:

Pharmaceutical, food, stationery, cosmetic, electronic products, toys, etc

Description:

QL5545 Automatic L-type sealer is developed for automatic operation. It is able to be integrated with production line. Objects are fed by conveyor and cut automatically.  Have protection device for cutting head in order to protect operator. Adopt stick-proof heating wire to cut and seal film. No smoking of film.Packed products are then fed into Tunnel for shrinking.

Specifications:  Auto L_Sealer

• Model QL5545 L type sealer
• Power source 220V/single phase, 50-60Hz
• Power 1.3 KW
• Max. Sealing size L500*W350*H100 mm
• Capacity 0-20 packs/min (depend on product size)
• Film type Center-folded polyolefin (POF) film
• Max. film size W600mm
• Air compressor 0.3m³/min
• PLC
• Machine material Painted body
• Machine dimension L1700*W900*H1400 mm
• Weight 320 Kg

Model BSD-4520 Shrink Tunnel

• Power source 380V/3PH, 50-60Hz
• Power 13 Kw
• Tunnel size L1200*W450*H200 mm
• Conveyor speed 0-15m/min
• Conveyor Chains with rotating silicon coated rods
• Machine material Painted body
• Machine dimension L1600*W730*H1400 mm
• Weight 210 Kg
